DXU24VF/1 CONTROL AND PARTS SET

DXU24VF/1 CONTROL AND PARTS SET

Parts List

Key:
Instock.
Nilstock.
Contact MRE.

Check the parts position number [ ] matching with the drawing. Login to view prices.

[1] In Stock
PJA505A228DJ
PWB ASSY (CONTROL)
Notes: ONLY FOR SUPPLY PARTS, CONFIRM SERVICE CODE BEFORE ORDERING - (CONTROL) LEFT OF TERMINAL BLOCK. CONFIRM SERVICE CODE-MANY PARTS ENDING 228 Show Image
PJA505A228DJ
[1-9] Contact
PJG501A003AL
CONTROL UNIT
Contact
Notes: !, NOT AVAILABLE
[2] In Stock
PJA505A235M
PWB ASSY (POWER)
Notes: ONLY FOR SUPPLY PARTS
[3] In Stock
SSA561B702
BLOCK,TERMINAL
Notes: TB1 Show Image
SSA561B702
[4] In Stock
SSA561B720A
BLOCK,TERMINAL
Notes: TB2 Show Image
SSA561B720A
[5] In Stock
SSA554B109
REACTOR
Show Image
SSA554B109
[6] In Stock
PSA551A001CG
SENSOR ASSY
Notes: THI-A Show Image
PSA551A001CG
[7] In Stock
PJG504A001B
WIRING(PWB)
Notes: CNW2 PWB- CNW1 PWB, CNW2 PWB- CNW1 PWB/ LENGTH 16.5CM (12 white wires) Show Image
PJG504A001B
[8] In Stock
PJF504A036A
WIRING(TB,POWER)
Notes: CONT E,TB1 1,TB1 2,TB1 3- CNW0 PWB,CNW3 PWB Show Image
PJF504A036A
[9] In Stock
PJF504A006K
WIRING(TB,XY)
Notes: TB2 X,TB2 Y- CNB PWB Show Image
PJF504A006K
[10] In Stock
PJG142A015A
LID ASSY,CONTROL B
[11] Contact
PJG011G003A
LABEL,WIRING
Contact
Notes: !
[12] Contact
PJZ502A024AB
Advanced Wired Remote
Contact
Notes: RC-EX1A, SALES ITEM - ECO TOUCH
[13] In Stock
SSA423A101A
HOSE,DRAIN
Notes: SEE C: CONTROL & PARTS SET
[13-15] Contact
PJF008A001W
PARTS SET
Contact
[14] In Stock
V300Y38
CLAMP
Notes: CLAMP Show Image
V300Y38
[15] In Stock
SSA153B016BA
INSULATION,PIPE
Show Image
SSA153B016BA
[16] Contact
PJG011F005BH
LABEL,MODEL NAME
Contact
Notes: !
SKU: DXU24VF/1 CONTROL AND PARTS SET Category:
